6A - 500A Full Range PCB Mount Terminal Block UL CUL VDE CQC CE Certificates
Descripition:
SCED professional in terminal blocks and we have 10 series, please select the right one for your market, and we will contact you soon. Below are more informations about our company and products' applications.
Certificates:
UL, CUL, CE, CQC, VDE, ISO9001, ISO14001, Patent, Honors, etc.
Company Informations:
Applications:
PCB, Frequency Converters, Server Site, Switch, Power Supply, Electric Lighting, Industry Control, Automation, Rail Transportation, Communication, Electric Power, Security, Medicine Equipment, Energy conservation, Elevator, below are some photos for review, etc..
Competitive Advantage:
- Stable good quality
- Competitive price
- Quickly response
- Full range products for selection
- Flexible to design the exact part per customers’ demand
For each products, we have the drawing and spec. like below, it's very convenience to check and compare.
Parameter and Drawing Specifications:
|
ULTechnical Data
|
B
|
C
|
D
|
|
Rated Voltage / Current V/A
|
300 / 30
|
300 / 30
|
|
|
Wire Range AWG
|
10-30
|
10-30
|
|
|
IEC Technical Data
|
|
|
Overvoltage Category
|
Ⅲ
|
Ⅲ
|
Ⅱ
|
|
Contamination Class
|
3
|
2
|
2
|
|
Rated Voltage / Current V/A
|
630 / 32
|
1000 / 32
|
1000 / 32
|
|
Rated Surge Voltage KV
|
6
|
8
|
6
|
|
Rated Connecting Capacity mm2
|
4.0
|
|
Material
|
|
|
Insulation Material / Inflammability Class
|
PA66 / UL94, V-0
|
|
Clamp Cage / Plating
|
Brass / Nickel Plated
|
|
Terminal / Plating
|
Brass / Tin Plated
|
|
Screw / Plating
|
Steel / Zinc Plated
|
|
Other Data
|
|
|
PCB Hole Diameter mm
|
φ1.9
|
|
Stripping Length mm
|
7-8
|
|
Screw / Torque / lbf.in
|
M3 / 4.4-5.3
|
For each series, we also have the promote photo look like below, hope this will help customer to find the exactly products more quickly.
